Cumbria Spends : Aggregation & Review

Posted : Blog Post : 07.07.2020 - North West Open Data

1. Update

I made a couple of changes form the last post regarding the Cumbrian spend data. I recreated the council specific staging tables and added two leading columns.

nwod_id_uri_code - the council ONS code, eg E07000028
nwod_id          - an auto incrementing identity value for the row

I also scripted the loads and did a full re-run of the tasks outlined previously. I’d emailed Copeland Borough Council and they got back to me very promptly with the two missing months CSV files. Eden District Council also got back to me with the corrected date data and provided me with 9 new files, unfortunately the November2019 file still had the date problem. I’ve decided to set aside Government Procurement card, credit card data for the time being.

2. Next Steps

The six councils reported a different number of columns of data in their CSV files, this varied from 7(Barrow) to 15(South Lakes). I created a spreadsheet of all the file headers. Some were easy to map, for instance ‘payment_amount’, ‘payment_date’, ‘supplier_name’. Others, for instance category required a bit more effort, checking out the number of unique types available in the data set. The spreadsheet can be found here. It’s not perfect as some files didn’t contain the data fields to map or I used a high level category value where no directorate information was available.

Using the LGA data validator page I came up with a table definition for an aggregated table. The items I chose where mainly mandated items and one recommended item. I then created this in PostgreSQL

create table organisation_expenditure_v1
(
        nwod_id_uri_code char(20) NOT NULL,
        nwod_id int NOT NULL,
        org_short_name character varying NOT NULL,
        org_directorate character varying,
        service_category character varying,
        beneficiary_name character varying,
        payment_date date,
        amount numeric(20,2),
        purpose_of_spend character varying,
        merchant_category character varying
);

The table columns are defined below

Table 1. organisation_expenditure_v1
Column Number	Column Name	Data Type	Description
1	nwod_id_uri_code	varchar	ONS district code. eg E07000026 for Allerdale
2	nwod_id	int	The auto generated row number from the council staging table, used for quick look ups of the original non aggregated data rows
3	org_short_name	varchar	single word name for a council
4	org_directorate	varchar	Directorate, service or department where an expense ocurred
5	service_category	varchar	A high level category for the spend. CIPFA SerCOP objective category label
6	beneficiary_name	varchar	Recipient of the spend
7	payment_date	date	The payment date as recorded in the department’s purchase or general ledger (yyyy-mm-dd)
8	amount	numeric	The actual value of the payment net of recoverable VAT
9	purpose_of_spend	varchar	Description of the purpose of the expenditure
10	merchant_category	varchar	General headings that describe the nature of expenditure, for example, computers, software etc.)/Common Procurement Vocabulary(CPV) category of spend or Proclass label

To get the data into the main aggregated table I created a population SQL file for each council that selected all the data out of the staging table and into the final table, this is where I mapped the staging columns to the target table and converted the ‘payment_amount’ into a numeric data type.

insert into organisation_expenditure_v1
(
        nwod_id_uri_code,
        nwod_id,
        org_short_name,
        org_directorate,
        service_category,
        beneficiary_name,
        payment_date,
        amount,
        purpose_of_spend,
        merchant_category
)
select
        nwod_id_uri_code,
        nwod_id,
        'allerdale',
        Service_Area,
        Expense_Type,
        Supplier_Name,
        Date,
        CAST(Amount as numeric(20,2)),
        Narrative,
        NULL
from allerdale_spend_2019;

I only had one error on the numeric conversion where a South Lakes value had a series of spaces instead of a valid amount. I updated this to ‘NULL’ value – ie ‘not know’ rather than zero.

3. Sanity Checking the Table

3.1. Data Coverage

The first thing I wanted to look at is how much data is available in the table so looked at the number of columns with NULL values in them

  council   | tot_rows | od_nulls | sc_nulls | bn_nulls | pd_nulls | a_nulls | pos_nulls | mc_nulls
------------+----------+----------+----------+----------+----------+---------+-----------+----------
 allerdale  |     5859 |       57 |        3 |        0 |      305 |       0 |         0 |     5859
 barrow     |     3269 |     3269 |        0 |        0 |        0 |       0 |         0 |     3269
 carlisle   |     8364 |        0 |        0 |        0 |        0 |       0 |         0 |     8364
 copeland   |     1850 |     1850 |        0 |        0 |        8 |       0 |         0 |     1850
 eden       |     1612 |        3 |        0 |        0 |        0 |       0 |         0 |     1612
 southlakes |     6895 |        2 |        2 |        2 |        2 |       3 |       167 |     6895
(6 rows)

I’ve split the data out by councils the columns are defined below

tot_rows – total number of rows of data per council
od_nulls – number of NULL values in org_directorate column
sc_nulls – number of NULL values in service_category column
bn_nulls – number of NULL values in beneficiary_name column
pd_nulls – number of NULL values in payment_date column
a_nulls – number of NULLS in amount column
pos_nulls – number of NULLS in purpose_of_spend column
mc_nulls – number of NULLS in merchant_category column

From this we can see that there is no merchant_category data also the org_directorate data is missing for two councils. We do have quite good coverage for service_category, beneficiary_name, payment_date, amount and purpose_of_spend.

3.2. Amount Column

Absolute min/max values per council

select org_short_name,min(amount),max(amount)
from organisation_expenditure_v1
group by org_short_name order by org_short_name;
 org_short_name |    min    |    max
----------------+-----------+-----------
 allerdale      | -37500.00 | 378102.25
 barrow         | -21948.61 | 481805.53
 carlisle       | -22513.04 | 250651.12
 copeland       |  -4230.00 | 442558.02
 eden           |  -9870.66 | 240000.00
 southlakes     | -13460.00 | 295329.00
(6 rows)

So we can see from the above that there are some quite large negative values in the table, this isn’t surprising as these values are from a ledger system so repayments or refunds will have line entries. It also means that the general title of ‘Spends over £500’ isn’t as simple as it sounds! Now let’s look at the minimum/maximum values above and below zero

Max/mins above zero

select org_short_name,min(amount),max(amount)
from organisation_expenditure_v1
where amount > 0 group by org_short_name;
 org_short_name |  min   |    max
----------------+--------+-----------
 carlisle       |   0.07 | 250651.12
 barrow         | 400.93 | 481805.53
 southlakes     |   0.60 | 295329.00
 eden           | 500.00 | 240000.00
 copeland       | 500.00 | 442558.02
 allerdale      |   0.01 | 378102.25
(6 rows)

Max/mins below zero

select org_short_name,min(amount),max(amount)
from organisation_expenditure_v1
where amount < 0 group by org_short_name;
 org_short_name |    min    |   max
----------------+-----------+---------
 carlisle       | -22513.04 |   -0.02
 barrow         | -21948.61 | -503.20
 southlakes     | -13460.00 |   -2.15
 eden           |  -9870.66 | -528.00
 copeland       |  -4230.00 | -522.82
 allerdale      | -37500.00 |   -0.01
(6 rows)

So from this we can infer that Carlisle, South Lakes and Allerdale Councils report all data down to the penny and Barrow, Eden and Copeland apply a lower limit, £500 for Eden and Copeland and £400 for Barrow.

3.3. Beneficiary_name Column

Let’s look at a selection of distinct types from this column

Same Company Different Case

A W Blake Ltd | carlisle | 5
A W BLAKE LTD | allerdale | 1

Case difference - Ltd vs Limited, Names incorrect

ADECCO RECRUITMENT | allerdale | 354
ADECCO UK LIMITED | southlakes | 257
Adecco UK Ltd | carlisle | 195
ADECCO UK LTD | copeland | 2

Name Variations

AQUILA TRAINING | barrow | 1
AQUILA TRAINING SERVICES | southlakes | 1
AQUILA TRAINING SERVICES LTD | allerdale | 1

Are These the Same Companies

BINGHAM YATES & PARTNERS | eden | 1
BINGHAM YATES LIMITED | allerdale | 2
Bingham Yates Ltd | carlisle | 4

Name Variations & Building account Segregations

BRITISH GAS | allerdale | 13
BRITISH GAS | copeland | 2
BRITISH GAS | allerdale | 16
BRITISH GAS - PAYMENT AREA 60 | allerdale | 1
BRITISH GAS (CLEATOR MOOR OFFICES) | copeland | 4
BRITISH GAS (HAIG ENTERPRISE PARK) | copeland | 1
BRITISH GAS BUSINESS | barrow | 3
British Gas Trading Ltd | carlisle | 1
BRITISH GAS TRADING LTD | barrow | 1
WATER PLUS | copeland | 14
WATER PLUS | eden | 9
WATER PLUS CIVIC HALL – 4221709037 | copeland | 1
WATER PLUS CIVIC HALL \u0096 4221709037 | copeland | 1
WATER PLUS CLEATOR MOOR COUNCIL CENTRE 4097096061 & 4081844084 | copeland | 1
WATER PLUS COPELAND CENTRE CBC 4043252188 | copeland | 8
Water Plus Limited | carlisle | 83
WATER PLUS LTD | barrow | 100
WATERPLUS | allerdale | 6
WATERPLUS | allerdale | 6
WATERPLUS PAYMENTS | copeland | 1

Name Variations/Mis spellings

Gates Travel | carlisle | 43
GATES TRAVEL | allerdale | 12
GATES TRAVEL | copeland | 1
GATES TRAVEL SERVICE | southlakes | 43
GATESTRAVEL | eden | 7

Spaces at the end of strings

N POWER | allerdale | 184
N POWER | allerdale | 169

More N Power Variations Technically all of these should be NPOWER LIMITED as per The Companies House website. https://beta.companieshouse.gov.uk/company/03653277

NPOWER | allerdale | 33
NPOWER | barrow | 153
NPOWER | copeland | 4
NPOWER | copeland | 2
NPOWER (BEACON K0520016) | copeland | 11
NPOWER (COPELAND CENTRE) | copeland | 12
NPOWER (CREMATORUIM) | copeland | 13
NPOWER (MORESBY PARKS) | copeland | 12
NPOWER LIMITED | allerdale | 1
Npower Ltd | carlisle | 163
NPOWER LTD | eden | 49
NPOWER LTD (TIC MARKET HALL) | copeland | 10
NPower Yorkshire Ltd | carlisle | 1

Large Companies and their Subsidiaries see https://beta.companieshouse.gov.uk/search?q=ZURICH+INSURANCE+MANAGEMENT

ZURICH INSURANCE COMPANY | copeland | 11
ZURICH INSURANCE GROUP LTD | barrow | 17
ZURICH INSURANCE PLC | eden | 4
ZURICH MUNICIPAL | allerdale | 7
ZURICH MUNICIPAL | southlakes | 1
ZURICH MUNICIPAL (BACS) | southlakes | 6
Zurich Municipal Insurance PLC | carlisle | 25
Zurich Municipal Management Servs | carlisle | 1

3.4. Service_category Column

Similar problems can be seen combining high level category definitions

Homeless | barrow | 1
Homeless support funding | barrow | 11
Homelessness | allerdale | 262
Homelessness | carlisle | 423
Homelessness | eden | 22
Homelessness Prevention & Priority Need | copeland | 8

If we look at the number of distinct service categories for each district you can see there are between 65 and 197 different categories in each council

select count(distinct(service_category)),org_short_name
from organisation_expenditure_v1 group by org_short_name;
 count | org_short_name
-------+----------------
   197 | allerdale
   198 | barrow
    65 | carlisle
   111 | copeland
    83 | eden
   189 | southlakes
(6 rows)

3.5. Payment_date Column

The dates vary from December 2008 to January 2020

select org_short_name,min(payment_date),max(payment_date)
from organisation_expenditure_v1 group by org_short_name;
org_short_name |    min     |    max              (1)
 ----------------+------------+------------
 carlisle       | 2019-01-03 | 2019-12-31
 barrow         | 2019-01-02 | 2019-12-27
 southlakes     | 2018-12-05 | 2019-12-19
 copeland       | 2019-01-04 | 2019-12-18
 eden           | 2008-12-13 | 2019-12-30          (2)
 allerdale      | 2018-12-20 | 2020-01-15
(6 rows)

select count(*)
from organisation_expenditure_v1
where payment_date < '2019-01-01';
 count
 -------
    89                                             (3)
(1 row)

1	Range of payment dates by council
2	The ‘2008-12-13’ date seems to be an error, all the other earlier dates relate to 2018 most of them from November onwards
3	Number of dates less that 2019-01-01

3.6. Org_directorate Column

Again there are various classifications used by each council, some councils don’t report any so this column probably won’t be that useful for future queries

select count(distinct(org_directorate)),org_short_name
from organisation_expenditure_v1 group by org_short_name;
 count | org_short_name
-------+----------------
    13 | allerdale
     0 | barrow
   206 | carlisle
     0 | copeland
    23 | eden
    27 | southlakes
(6 rows)

4. Conclusions

Clearly this aggregated data set has some issues with respect to cross council comparisons. To review the columns

nwod_id_uri_code – Created as part of the load
nwod_id – Created as part of the load, provides a quick look up to the original staging table
org_short_name – Created as part of the load
org_directorate – No consistent cross council data
service_category – There may be a possibility of creating a look up table to create a dozen or so broad divisions
beneficiary_name – A lot of the problems described here could be fixed, eg make all the values upper case, change all ‘LIMITED’ to LTD, normalise all names etc
payment_date – Quite good data
amount – Quite good data, may have to consider limiting all data sets to +/- £500
purpose_of_spend – This is largely free text, useful for looking at specific items rather than cross council analysis
merchant_category – No data provided

I think the next step will be to try and make some of the ‘improvements’ outlined above and start thinking about some of the information that can be extracted from the data. I’m reasonably happy with the amalgamated table, but I need to ‘improve’ the quality beneficiary and category columns without losing accuracy.
